R410A50Hz Universal Outdoor Series Technical Manual 4 -way Cassette Indoor Unit
37
GD Chigo Heating & Ventilation Equipment Co., Ltd.
No.
Part Name Quantity
1
E
letric control components for indoor unit
1
1.1
E-parts box cover assembly
1
1.2
Pressure line buckle
1
1.3
Electrical box welding components
1
1.4
Fan motor capacitor
1
1.5
Terminal
1
1.6
E-parts board
for indoor unit
1
1.7
Temperature sensor
1
1.8
Temperature sensor
1
2
W
ind inlet guide
1
3
Pressure line buckle
1
4
Water pan components
1
5
Evaporator components
1
5.1
Insulating pipe
1
5.2
Insulating pipe
1
5.3
attached cotton
1
5.4
Damping glue 1
5.5
Evaporator welding assy
1
5.5.1
Instalation tube for probe
1
5.5.2
Evaporator
1
5.5.3
collecting pipe welding assy
1
5.5.4
Current divider capillary assy
1
6
Evaporator tightening
1
7
End plate fixing plate
1
8
Centrifugal leaves
1
9
Main fixing board
1
10
Motor bracket
1
11
Pump parts
1
11.1
Water pump
1
11.2
Water pump support frame
1
11.3
Water pump filter
1
11.4
Water pump gasket 1
1
11.5
Water pump gasket 2
1
11.6
Water level switch
1
12
Chassis foam components
1
13
Hanging ear 1
1
14
Hanging ear 2
3
15
Rear panel assembly
1
15.1
Rear panel
1
15.2
Rear panel insulation cotton
1
16
Front panel assembly
1
16.1
Front panel
1
16.2
Front cover insulation cotton
1
17
Chassis parts
1
17.1
Chassis welding components
1
17.2
Chassis external insulation cotton
1
18
Refrigerant tube support plate assembly
1
19
Drain pipe assembly
1
