Chigo CCB-12HR1 User Manual

R410A50Hz Universal Outdoor Series Technical Manual 4 -way Cassette Indoor Unit
41
GD Chigo Heating & Ventilation Equipment Co., Ltd.
No.
Part Name
Quantity
No.
Part Name
Quantity
1
E-box cover
1
8.4.1
Installation tube for probe
1
2
Electric control components for
indoor unit
1 8.4.2 Evaporator 1
2.1
Transformer
1
8.4.3
Collecting assy for evaporator
1
2.2
Fan motor capacitor
1
8.4.4
Shunt capillary assy
1
2.3
Terminal
1
8.5
Main fixing board
1
2.4
Terminal
1
9
Chassis plate
1
2.5
Electric control board for indoor
unit
1 10 Upper foam components 1
2.6
Temperature sensor
1
10.1
Upper foam
1
2.7
Temperature sensor
1 11
Pre-assembling assy for
water pump
1
2.8 Welded chassis for E-box 1 11.1 water pump support 1
3
Wind inlet guide assy
1
11.2
Water pump
1
3.1
Wind inlet guide
1
11.3
Liquid-level sensor
1
4 Water pan components 1 11.4
Underlay for water pump
support
3
4.1
Water pan
1
12
Hanger
4
4.2
Water pan foam
2
13
Rear brattice
1
5
Centrifugal fan
1
14
Chassis assy
1
6
Fan motor for indoor
unit(YDK-75Q-6P3-1)
1 15 Discharge pipe joint 1
7
Auxiliary fixing board for
evaporator
2 16
Side maintenance board for
water pump
1
8
Evaporator components
1
17
Front brattice
1
8.1
Insulating pipe
1
18
Lower tube clamp
1
8.2
Insulating pipe
1
19
φ35 Lower tube clamp
1
8.3
Evaporator attached cotton
1
20
Upper tube clamp
1
8.4
Evaporator welding assy
1
21
φ35 Upper tube clamp
1
22
Valve plate
1
