R410A50Hz Universal Outdoor Series Technical ManualFloor ceiling
95
GD Chigo Heating & Ventilation Equipment Co., Ltd.
Refrigera
nt piping
Liquid side/Gas
side
mm Φ9.52/Φ19.05 Φ9.52/Φ19.05 Φ9.52/Φ19.05 Φ9.52/Φ19.05
Drainage pipe
mm
25
25
25
25
Standard controller Standard for remote controller(wired controller for option)
Operatio
n temp
°C
16～32 16～32 16～32 16～32
Ambient temp
°C
-7
～
50
-7
～
50
-7
～
50
-7
～
50
Application area
m
2
55~95
55~95
60~105
60~105
Stuffing
Quantity(20'/40'/40'HQ)
set 60/120/123 60/120/123 60/120/123 60/120/123
Notes:
1. Nominal cooling capacities are based on the following conditions:
Indoor temp: 27°CDB, 19°CWB; Outdoor temp: 35°CDB; Equivalent ref. Piping: 5m(horizontal)
2.Nominal heating capacities are based on the following conditions:
Indoor temp: 20°CDB; Outdoor temp: 7°CDB, 6°CWB; Equivalent ref. Piping: 5m(horizontal)
3. Actual noise level may differ, depending on the room structure, etc, since these noise values are from an
anechoic room.
