E9
*8 If one of following options is added, select an appropliate code for OP.
Code
Waterproof
specifications
Output scaling Lower limit burnout
Square root
calculation
Open-loop system ON-OFF
servo specifications
1 ● ― ― ― ―
A
*9
― ● ― ― ―
B ― ― ● ― ―
C ― ― ― ● ―
D ― ― ― ― ●
E
*9
● ● ― ― ―
F ● ― ● ― ―
G ● ― ― ● ―
H ● ― ― ― ●
*9 It can be specified when the control algorithm is PID control.
*10 DB67 only.
Cleaning: Clean gently the front panel and keys of this instrument with
a soft moistened cloth (not too wet). Do not use a dry cloth
for cleaning the LCD display for risk of static electricity. (If
the LCD is accidently charged by static electricity, the LCD
will turn back to normal for several minutes.) Do not use
organic solvents such as alcohol.
Overhaul: To maintain reliable operation for a long time, we
recommend an overhaul after two or three years. If the need
of overhaul arises, contact the dealer or your nearest
CHINO office.
See the following table for the obvious consumable parts used in the
instrument. Generally, most of the parts are subject to change or
degradation over time.
Part name Expected life
Relay
*For control and event outputs
Approx. 100,000 times
Electrolytic capacitor
*Smoothing capacitor for power
circuit
Approx. 5 years
(Ambient temperature: 30°C,
operation time: 12 hours/day)
When an inappropriate setting or operation is performed, the warning
No. shown below will be displayed for approx. three seconds. Check
the warning contents and try appropriate setting or operation.
Warning No. Warning contents

Program operation cannot be executed.
Check that the program pattern is set correctly.

Feedback tuning fails or the zero adjustment value
of servo exceeds the span adjustment value. Check
the feedback input line if the connection is done
properly for the OPEN and CLOSE sides.
□
Key lock is active. Set "Key lock (MODEt)" to
"Function OFF". When a parameter is changed
during a writing process via communication, the key
lock becomes active temporarily to restrict the key
operation. To change a parameter by keys, stop the
writing process via communication, and change the
screen once using the [▼SEL] or [▲SEL] key.
When an error occurs in the system, the error No. shown below will be
displayed for approx. two seconds. Check the error contents and contact
the dealer or your nearest CHINO office.
Error No. Error contents
 A/D conversion error of PV/RJ
 A/D conversion error of feedback/remote signal input
 Calibration data error
Each function does the next movement in the error display.
Item 

(Feedback
abnormality)

(Remote
abnormality)

PV * * *
Normal
operation
Feedback
measure
Normal
operation
*
Normal
operation
Normal
operation
Remote SV
input
Normal
operation
Normal
operation
*
Normal
operation
Control output
Normal
operation
Normal
operation
Normal
operation
Normal
operation
Event output
Normal
operation
Normal
operation
Normal
operation
Normal
operation
Transmission
output
Normal
operation
Normal
operation
Normal
operation
Normal
operation
Communication
Normal
operation
Normal
operation
Normal
operation
Normal
operation
External
signal input
Normal
operation
Normal
operation
Normal
operation
Normal
operation
*Renewal of input values are suspended.
 Input specifications
Input signal
Thermocouple B, R, S, N, K, E, J, T, U, L,
C(WRe5-WRe26)
, W-WRe26,
Platinel II, PtRh40-PtRh20, Au-Pt
DC voltage ±20mV, ±100mV, ±5V, ±10V
Resistance thermometer
Pt100, JPt100, Pt50
Accuracy rating ±0.1% of FS ±1digit of measuring range
See "Measuring range table" for details.
Reference junction compensation accuracy
±1.0°C (ambient temperature 23°C ±10°C)
±2.0°C (temperatures other than above)
Allowable input voltage Thermocouple ±10V DC
DC voltage (mV) ±10V DC
DC voltage (V) ±20V DC
Resistance thermometer ±5V DC
 Control specifications
Control interval Approx. 0.1 seconds
Output type ON-OFF pulse output, ON-OFF servo output (DB650
and DB670 only), current output, SSR drive pulse output,
voltage output
ON-OFF pulse output type:
Contact type 1a contact
Pulse cycle Approx. 1 to 180 seconds
Contact capacity
Resistive load 240V AC 3A, 30V DC 3A
Inductive load 240V AC 1.5A, 30V DC 1.5A
Minimum load 5V DC 10mA
ON-OFF servo output type:
Contact type 1a contact
Feedback resistance 100Ohm to 2kOhm
Contact capacity Resistive load 240V AC 3A, 30V DC 3A
Inductive load 240V AC 1.5A, 30V DC 1.5A
Minimum load 5V DC 10mA
