CHINT NA1-1000 User Manual

Type
Rated voltage (V)
NA1-1000
AC230 AC400
NA1-2000~6300
AC230 AC400
DC220
10
300VA
DC220
6
100VA
0.5
60W
Type
Rated control power voltage Us(V)
NA1-1000
AC230, 400
NA1-2000, 3200, 4000, 6300
AC400, 230, 127
DC220, 110
(0.85-1.1)Us
75VA
<4s
85/110/150W
<5s
Work voltage (V)
Power loss (W)
Energy-storage time
Operation frequency
DC220, 110
75W 192W
15.4 Motor-driven energy-storage mechanism
With the function of motor-driven energy storing and auto restoring energy after closing the circuit breaker, the mechanism can ensure
closing the circuit breaker instantly after breaking the circuit breaker.
Manual energy-store is available.
Characteristic
No more than 3 times per minute
15.5 Auxiliary contact
Standard model: 6N/O( normal open) and 6N/C(normal close).
Characteristic
conventional free-air thermal current Ith (A)
Rated control capacity
6
300VA
6
300VA
6
60W
15.6 Doorcase
Installed on the door of the distribution cubicle, for sealing the distribution cubicle and making the
protection class to IP40( fixed type and drawout type).
.51.
Air Circuit Breaker
Type
Rated control power voltage Us(V)
ST-DP
RS485
Rt
ST-DP
ST-DP
NA1 NA1 NA1
Monitor host
CP5×11Main
station card r
Communication connection diagram (Profibus-DP protocol)
Profibus-DP protocal networking
15. Accessories
15.1 Under-voltage release
a.Without power supply, under-voltage release can't close.
b.It is classified into instantaneous and time-delay type.
c.Delay time 0,1s,2s,3s,4s,5s,6s,7s are fixed for NA1-1000, 1s,3s,5s7s are fixed for NA1-2000,3200,4000,6300.
d.Within 1/2 time-delay range, circuit breaker does not trip when power voltage recovers and exceeds 85%Ue.
e.Characteristic
Close the circuit breaker before operation the circuit breaker.
NA1-1000
AC230, 400
NA1-2000, 3200, 4000, 6300
AC400, 230, 127
DC220, 110
(0.35-0.7)Us
(0.85-1.1)Us
≤0.35Us
20VA 48VA
Action voltage(V)
Reliable making voltage(V)
Reliable non-making voltage(V)
Power loss(W)
.50.
Type
Type
Rated control power voltage Us(V)
Rated control power voltage Us(V)
NA1-1000
NA1-1000
AC230, 400
AC230, 400
NA1-2000, 3200, 4000, 6300
NA1-2000, 3200, 4000, 6300
AC400, 230, 127
AC400, 230, 127
DC220, 110
DC220, 110
(0.7-1.1)Us
(0.85-1.1)Us
56VA
56VA
300VA
300VA
50±10ms
(50±10)ms
Work voltage
Power loss
Breaking time
Work voltage (V)
Power loss (W)
Closing time
15.2 Shunt release
Shunt release can realize the remote control to break the circuit breaker.
Characteristic
DC220, 110
DC220, 110
250W
250W
40W
40W
30~50ms
≤70ms
Forbid making the power for long time to avoid the shunt release being damaged.
15.3 Closing release
After the motor finishing the energy storage, closing release can instantly close the circuit breaker.
Characteristic
Forbid making the power for long time to avoid the closing release being damaged.
