CHINT NVF2G Series - Structural Features and Working Principle; Product Structure Feature Map

4
Structural features and working principle
4.1 Product structure feature map
Figure 4.1 NVF2G-1.5/PS4~NVF2G-11/PS4 external parts diagram
Figure 4.2 NVF2G-11/TS4~NVF2G-30/PS4 extermal parts diagram
FAN
Panel (Top)
Keyboard
Panel(Bottom)
INSTALL HOLE
SHELL
NAMEPLATE
BASEPLATE
FAN
Panel
Panel base
Keyboard
INSTALL HOLE
SHELL
NAMEPLATE
007
NVF2G Series Inverter User's Guide
