CHINT NVF2G Series - Start and Stop Method Setting

045
NVF2G Series Inverter User's Guide
8.2.10 frequency command limit (frequency setting )
Operating frequency upper limit: limit the maximum output frequency, and the motor is not allowed to
run above a certain frequency;
Lower limit of operating frequency: limit the minimum output frequency, and do not allow the motor to
run below a certain frequency;
Maximum output frequency: limit the maximum output frequency.
Function code
Name
Default value
Predetermined area
Parameter Description
F0.07
output frequency
50.00Hz
F0.08~600.00Hz
F0.08
frequency cap
50.00Hz
F0.09~F0.07
F0.09
Operating frequency
lower limit
0.00Hz
0.00Hz~F0.08
8.3 Start and stop method setting
8.3.1 Start method
There are three starting methods for the inverter, which are: start from the starting frequency , brake first
and then start from the starting frequency, and start after speed tracking . Set parameter F1.00 to select the
starting method of the inverter .
8.2.7 Communication setting main frequency
See Chapter 9 RS485- Modbus communication instructions for details .
8.2.8 Input setting of auxiliary frequency command
Set parameter F0.03 to select the auxiliary frequency command input, which is the same as the main
frequency command input selection method, the specific parameter selection and setting process can refer to
"8.2.1 Select the input method of the main frequency command".
8.2.9 Select main and auxiliary frequency superposition command
The relationship between the target frequency and the main and auxiliary frequency commands can be set
by parameter F0.04 .
Function code
Name
Default value
Predetermined area
Parameter Description
F0.03
Auxiliary frequency
source selection
0
0
Digital setting (F0.05 )
1 AI1
2 AI2
3
reserve
4
reserve
5
multi-segment command
6
Simple PLC
7
Closed-loop PLC
8
Communication given frequency
F0.04
Main and
auxiliary
frequency
source
operation
0x0000
0x0000 ~0x0031
Function
code
Name
Default
value
Predetermined
area
Parameter Description
Units: frequency source selection
0: main frequency selection
1: operation result
Tens place: main and auxiliary frequency source
operation
0: main + auxiliary
1: main + auxiliary
2: The maximum value of the two is MAX
3: The minimum value of both MIN
Function code
Name
Default value
Predetermined area
Parameter Description
F1.00
Starting mode
0 0~2
0 Start from the starting
frequency
1 Brake first and then start
from the starting frequency
2 speed tracking (including
direction judgment) restart
