CHINT NVF2G Series - Classification Table of Braking Unit and DC Reactor

Inverter model Input reactor DC reactor Output reactor
18.5 kW ACL-0040-EISCL-2 Installation not supported OCL-0040-EISCL-1
22 kW ACL-0050-EISCL-2 Installation not supported OCL-0050-EISCL-1
30 kW ACL-0060-EISCL-2 Installation not supported OCL-0060-EISCL-1
37 kW ACL-0090-EISCL-2 Installation not supported OCL-0080-EISCL-1
45 kW ACL-0090-EISCL-2 DCL-0115-EIDHL-4 OCL-0090-EISCL-1
55 kW ACL-0120-EISCL-2 DCL-0160-EIDHL-4 OCL-0120-EISCL-1
75 kW ACL-0150-EISCL-2 DCL-0180-EIDHL-4 OCL-0150-EISCL-1
90 kW ACL-0200-EISCL-2 DCL-0250-EIDHL-4 OCL-0200-EISCL-1
110 kW ACL-0250-EISH-2 DCL-0250-EIDHL-4 OCL-0200-EISCL-1
132 kW ACL-0250-EISH-2 DCL-0340-UIDHL-4 OCL-0250-EISH-1
160 kW ACL-0330-EISH-2 DCL-0460-UIDH-4 OCL-0330-EISH-1
185 kW ACL-0390-EISH-2 DCL-0460-UIDH-4 OCL-0330-EISH-1
200 kW ACL-0390-EISH-2 DCL-0460-UIDH-4 OCL-0390-EISH-1
220 kW ACL-0490-EISH-2 DCL-0650-UIDH-4 OCL-0490-EISH-1
245 kW ACL-0490-EISH-2 DCL-0650-UIDH-4 OCL-0490-EISH-1
280 kW ACL-0600-EISH-2 DCL-0650-UIDH-4 OCL-0530-EISH-1
315 kW ACL-0600-EISH-2 Internally installed OCL-0600-EISH-1
355 kW ACL-0800-EISH-2 Internally installed OCL-0660-EISH-1
400 kW ACL-0800-EISH-2 Internally installed OCL-1000-EISH-1
450 kW ACL-1000-EISH-2 Internally installed OCL-1000-EISH-1
Notice
1. Optional built-in braking unit needs to be customized.
2. When the brake assembly is connected externally:
1) The polarities of , (or , or , ) cannot be reversed, otherwise there is a risk of damaging
the frequency converter, or even causing a fire;
2) The wiring length of the brake unit should not exceed 10 m , and twisted-pair or tight double-wire parallel
wiring should be used.
3. When connecting external braking components or external braking resistors, please change the "overvoltage
stall gain" to "prohibited" (the parameter number of FE.05 is " 0"), otherwise, within the set deceleration
time will not stop.
+1 +2
A.3 Classification table of braking unit and DC reactor
Table A.3 Classification table of braking unit and DC reactor
1
Standard built-in brake unit
2
Optional built-in brake unit
3
Optional external braking unit
4
Does not support the installation of DC reactors
5
Optional external DC reactor
6
7
Standard built-in DC reactor
Serial number
Functional Classification
Power section
086
NVF2G Series Inverter User's Guide
Notice
Standard external DC reactor
(1) Both the input reactor and the output reactor are external options, and the recommended
models are shown in the table;
(2) See the table for the configuration of DC reactors, 1.5P~45P is not configured, 45T~110P is an
external optional DC reactors, 110T~315P is an external standard DC reactors, 315T~450T is
applied for internal standard DC reactors
NVF2G-1.5P-S4~NVF2G-30P-S4
NVF2G-30T-S4~NVF2G-110P-S4
NVF2G-110T-S4~NVF2G-450T-S4
NVF2G-1.5P-S4~NVF2G-45P-S4
NVF2G-45T-S4~NVF2G-110P-S4
NVF2G-110T-S4~NVF2G-315P-S4
NVF2G-315T-S4-L~NVF2G-450T-S4-L
