IRIS Touch Engineering Manual Version 1.4 Page 13 of 40
Configuration from Texecom Premier panels via Serial TTL
The IRIS range has been fully integrated into the Texecom Premier Alarm panel range and most configurations can
be configured from the panel keypad.
Note: For GPRS connections you will need to enter in the GPRS settings (e.g. APN).
With the latest integration on the Texecom Premier Elite panel this configuration is possible via the keypad. For
older / different models it is currently not possible to configure the GPRS settings (e.g. APN) from the keypad as
the Texecom has no entry method.
Connect the IRIS Touch dialler via the TTL header to the Texecom Com 1 header as indicated in Section 7.3
“Connections”, then power up the Texecom panel, if not already powered up.
IRIS Touch 600 or 640 with GPRS connection:
For GPRS versions, the APN can be configured via an SMS message from any mobile phone.
If GPRS is used, you will need to set the GPRS APN. On the latest Texecom Premier Elite panel you can do this via the
keypad and this is detailed in the configuration below. For older / different models that do not have the keypad
option you can do this by sending a text message to the phone number of the SIM card being used. The text should
be in the format:
AT%G10=’apn’
Where ‘apn’ is the Access Point Name for the SIM, e.g. ‘orangeinternet’.
Note: The APN must be configured before the IRIS Touch is polling as after the dialler is polling all SMS
configurations will be rejected for security reasons.
On the next page is a detailed description of the configuration setting for the latest Texecom Premier Elite range. If
you have different version of the Texecom Premier range or want to perform upload/download connection via
Wintex then please refer to the IRIS Texecom Premier Installation manual or IRIS Remote Service App Client User
Guide for Texecom range from http://www.chironsc.com/downloads_security.html.
