7. Installing the IRIS Touch Dialler
Use the following procedure to install your IRIS Touch dialler:
Mounting
Choose a suitable location, taking into consideration the routing of both power and dialler interface cables, within
the alarm panel or separate enclosure. Secure the dialler within the enclosure using the fitted standoff or the
alternative self-adhesive feet.
Note: For EN50131-10 compliance you must use the supplied standoff and not the self-adhesive feet.
Power
The IRIS Touch dialler can be powered from a separate or Aux 9-28V DC power supply specified to deliver up to 1A
current using the screw terminals, or receive power directly via the 4 or 5 Pin Molex connector (RS485 or RS232 TTL)
headers indicated in Section 5 “Board Configuration”.
Note: For Radio & Telecoms Terminal Equipment Directive compliance the power cable must be no longer than 3
meters in length.
Fit the power cable. DO NOT APPLY POWER TO THE DIALLER UNTIL INDICATED.
Connections
Connect cables to the PCB for your system as shown on in Section 5 “Board Configuration”.
Ethernet enabled systems (IRIS Touch 620NG & 640NG): Ethernet socket LAN1.
Connect the Ethernet cable from ‘LAN1’ to the local IP router/switch or socket that has been allocated for the
LAN/WAN network IP connection.
GPRS/3G enabled systems (IRIS Touch 600NG & 640NG): Cell Ant. Fit the supplied T-bar GPRS/3G antenna but
do not fix in place until after performing the GPRS/3G network scan.
Note: An external GPRS/3G antenna can be fitted if required.
6 x Pin Inputs.
Optional serial connection
The following 5 connections are optional and depend on the panel connection method to be used.
By default the IRIS Touch RS485 connection is for Honeywell Galaxy panels and the Serial TTL header is for Texecom
Premier panels.
Note: For alternative selections for other panel connection you will need PC/Laptop connected via USB to change
the configuration of the IRIS Touch please contact Chiron for further details, or download the full panel
installation manual available from http://www.chironsc.com/downloads_security.html.
RS485 currently available for Honeywell Galaxy data bus (Alarms and Upload/download) or Risco ProSys bus
(Upload/download) connections (optional).
RS485 4pin header (Molex) currently available for Honeywell Galaxy data bus connections (optional).
Serial (TTL) currently available for Texecom Com1 connections (optional).
RS232 port 1 screw terminal (optional for Hayes command terminal).
RS232 port 2 screw terminal (optional for integrated panel connection).
For more details on the cable requirements / connections please see detail on next page.
