BF-480M User’s Guide
- 33 -
Return Successful Packet
Length(Bytes) 2 2 32 32 2 1
0xF0F0 0x0002 Data1 Data2 0xF0F0 CRC
Data1
Data[0] Data[1] Data[2] Data[3] Data[30] Data[31]
IN-1 IN-2 IN-3 IN-4 reserved reserved
IN-1: state of IN1, 0 for SHORT, 1 for OPEN
IN-2: state of IN2, 0 for SHORT, 1 for OPEN
IN-3: state of IN3, 0 for SHORT, 1 for OPEN
︱
IN-12: state of IN12, 0 for SHORT, 1 for OPEN
Data2
Data[0] Data[1] Data[2] Data[3] Data[30] Data[31]
OUT-1 OUT-2 OUT-3 OUT-4 reserved reserved
OUT-1: state of OUT1, 0 for SHORT, 1 for OPEN
OUT-2: state of OUT2, 0 for SHORT, 1 for OPEN
OUT-3: state of OUT3, 0 for SHORT, 1 for OPEN
︱
OUT-6: state of OUT6, 0 for SHORT, 1 for OPEN
2. Trigger Digital I/O
Length(Bytes) 2 2 32 32 2 1
0xF0F0 0x0003 Data1 Xxx
(don’t care)
0xF0F0 CRC
Data1
Data[0] Data[1] Data[2] Data[3] Data[30] Data[31]
OUT-1 OUT-2 OUT-3 OUT-4 reserved reserved
OUT-1: the value you want to write into OUT1, 0 for SHORT, 1 for OPEN
OUT-2: the value you want to write into OUT2, 0 for SHORT, 1 for OPEN
OUT-3: the value you want to write into OUT3, 0 for SHORT, 1 for OPEN
︱
OUT-3: the value you want to write into OUT3, 0 for SHORT, 1 for OPEN
