BF-480M User’s Guide
- 7 -
2.2 LED status
LED Color(s) Activity Desc.
Off Power OFF
Red Blinking Booting/System Self-Test
Power Red
Red On Device Ready
Off No Ethernet Link
Link Green
Green On Ethernet Link established
Off 10 Mbps
SPD
Green
Green 100 Mbps
Off No data activity
Ethernet
(on the RJ-45
connector)
ACT
Green
Green
Blinking
Transmitting/Receiving
Off No TCP/IP session link
Green On TCP/IP session link established
Transaction
Link
Green
Green
Blinking
Data Sending/Receiving between Serial and
Ethernet
RS232 Green Blinking Data Sending/Receiving through this COM port
RS485 Green Blinking Data Sending/Receiving through this COM port
2.3 Initial Setup
Use this section to set up your computer to assign it a static IP address in the 192.168.0.1 to 192.168.0.254
range with a subnet mask of 255.255.255.0. This is necessary to ensure that your computer can communicate
with your BF-2300.
Your computer must have an Ethernet card and TCP/IP installed. TCP/IP should already be installed on
computer using Windows 98/2000/XP and later operating systems.
Note: Connect a computer to BF-2300 Ethernet port directly should be with crossover Ethernet cable, if
both connect to hub/switch should be with straight-through Ethernet cable.
