Appendix B: Hardware Reset Button
BF-2300 provides a hardware reset button with multi-functions as below:
Reset Button
Mode Action Result
Push reset button one time System restart right away
System in working mode
Keeping push reset button 2-3
seconds
System reset to factory
default
Push reset button one time System reset to factory
default
System power on
Keeping push reset button 2-3
seconds
System running in boot loader
and waiting for firmware
upgrade by Xmoden.
