Chiyu Technology BF-2300 User Manual

CHIYU TECHNOLOGY CO., LTD.
No.28, Renai Rd., Chiayi, 600, Taiwan Tel：(886) 5-2835460 Fax：(886) 5-2835458
BF-480M User’s Guide
- 4 -
Product Specifications
CPU 16 bit CPU, 100MHz
Memory 256 KB ROM & 1MB SDRAM
Watch Dog Support watch Dog, system never halt
Hardware
Reset Button Multi-function for system restart and factory default reset
Ethernet
1 RJ-45 Port 10/100Base-T,half/full duplex, Auto Cross Over, 1.5 KV Magnetic protected
Serial
Port Interface Port Type signals protection
COM1 RS-232
Screw
Terminal
TxD,RxD,RTC,CTS,DTR,DSR,DCD,GND 15KV ESD
COM2 RS-485
Screw
Terminal
D+, D- 15KV ESD
I/O
18 channel I/O 12 Isolated DI/6 Isolated Relay DO
Isolated Digital Input
Optical Isolation: 2,500V(DC)
Over-voltage Protect: 70V(DC)
Dry Contact
Interface
Relay Digital Output Optical Isolation: 2,500V(DC)
Contact rating: AC:120V@0.5A
DC:30V@1A
Total switching time:10msec(on:7/off:3)
Ethernet
Static IP/DHCP Client/PPPoE
Serial
Parity Check None, even, odd, Mark, Space
Data bits 5, 6, 7, 8
Stop bits 1, 2
Configuration
Flow Control RTS/CTS, XON/XOFF
Supported OS
Windows XP, Windows 2000, Windows NT, Windows95/98 ME, Linux,
UNIX
Protocol
TCP, IP, UDP, Telnet, ARP, DHCP, ICMP、SMTP、PPPoE、HTTP、DDNS
Support TCP/UDP Server/Client mode
User name & password protected for web management
Built-in Http server for set up and remote management via any browser
easily
Support backup & restore system configuration data
Management
Support Windows 95/98/ME/NT/2000/XP/2003 virtual COM drivers
Power requirement DC 9-30V ,500mA
Operation Temp.
0 ~ 55℃
Operation Humidity 5 ~ 95%RH
Storage Temp.
-20 ~ 85℃
Size 81X103X30 mm
Magnetic protected Ethernet port 1.5 KV
Power
&
Environment
A
pproval FCC, CE
