Chopin SDmatic - Page 71

71
User’s manual 
12/2016
GB
SDmatic
■ Measurement units selection
To select the units UCD, AACC, Farrand) displayed at the end of
the test and printed on the ticket, press in the the user calibration
icon.
Use the arrows and to switch from one calibration to an
other. Press on or to select or to deselect the calibration.
Press on "OK" to validate or on to exit without saving.
Printout example
------------------------------------------
SDmatic CHOPIN
- - - - - - - - -1.50 - - - - - - - - - - -
CHOPIN
ZI Val de Seine
92390 VLG
France
- - - - - - - - - - - - - - - - - - - - - - -
09:17:31 02/11/05
No Sample: 31
- - - - - - - - - - - - - - - - - - - - - - -
A
I
% : 95.59%
UCD : 25.1
UCDc : 25.1
AACC76-31 : 5.96
Farrand : 37.79
Vabs : 30 s
H2O : 14.00%
Protéine : 12.00ms
Farine : 1.085g
------------------------------------------
User calibration
