CHORE WARRIOR 44322 - Parts Inventory

4 chorewarrior.com Customer Service: 651-370-7508
PARTS INVENTORY
A
B
C
D E
F
G
H
I
J
K
L
M
N
O
R
T
V
U
W
X
Y
S
P
Q
A. Tires (Qty: 2)
B. Axles (Qty: 2)
C. Motor
D. Tray brace
E. Battery box
F. Right handle with throttle
G. Left handle
H. Electronics box
I. Battery charger
J. Left support leg
K. Right support leg
L. Left axle frame mount
M. Right axle frame mount
N. Dump support brace
O. Axle key-way (Qty: 2)
P. Axle nuts (Qty: 2)
Q. Axle ange gaskets (Qty: 2)
R. Axle ange screws (Qty:10)
S. Zip ties (Qty: 6)
T. M8 hex nuts (Qty: 20)
U. M8 x 25mm carriage bolts (Qty: 6)
V. M8 x 40mm hex bolts (Qty: 14)
W. M10 x 20mm hex bolts (Qty: 4)
X. Motor oil
A. 44257
B. L: 44345
R: 44344
C. 44342
D. 44319
E. 44362
F. 44312
G. 44311
H. 44329
I. 44375
J. 44317
K. 44318
L. 44339
M. 44340
N. 44316
O-W hardware
pack: 44387
X. 44359
Y. Washers
ITEM #s:
= LEFT = RIGHT
Tools Required for Assembly
• 27mm or 1 1/16" socket/wrench • 12mm socket/wrench
• 16mm or 5/8" socket/wrench • 10mm socket/wrench
• 13mm or 1/2" deep socket/wrench • 6mm Allen wrench
both rachet and extension
