Programmable AC Source 61511/61512/61611/61612 Quick Start Guide
4
Cursor Movement Keys: These four
keys move the cursor in different
directions. In normal mode, pressing any
of these four keys will change the cursor
position.
5
SAVE/RECALL
SAVE or RECALL: Press this on MAIN
PAGE can save the output setting. By
pressing this key on CHOICE PAGE
users can save the system data.
6
OUT/QUIT
OUT/QUIT: Press this key to
Enable/Disable the output voltage of the
AC source.
7
LOCAL/REMOTE
LOCAL/REMOTE: Switches the
“Remote” control mode to“LOCAL” from
front panel input.
8
OUTPUT SETTING
OUTPUT SETTING:
Changes the screen to “Output: More
Setting” for additional settings.
9
CURSOR
CURSOR: It is used to set or adjust the
value.
10
LOCK
LOCK:
Press it for 1 second can lock up “all
keys” and the “rotary”.
Press it for 3~3.5 seconds to unlock
them.
11
PHASE
PHASE:
It sets single/3-phase.
12
CONFIG
CONFIG:
It changes the screen to “config choose
page” for various settings.
13
0
to
9
and
●
Numeric and Decimal:
Users can use “numeric keys” and
“decimal key” to input digital data.
14
Õ / -
Backward and Decreasing: Press this
key to delete the inputted number. It
shows " - " if no number exists.
15
EXIT &
EXIT:
Press it to return to previous screen.
16
Main Power Switch: It turns on or shut
off the power.
3
To Next Page
