Local Operation
2. Setting the Sequence Mode
There are three modes to control the method of sequence execution.
SKIP: Skip the sequence. Load will not change the input status.
AUTO: Use ON/OFF time to control Load input on/off. When ON/OFF time
passes, the Load will get to the next sequence automatically.
MANUAL: Use ▲, ▼ or number 0 to 9 to control the execution sequence. Pressing
number key lets you select a random sequence number to execute.
Pressing 0 means to go to sequence 10.
Press 2, ENTER keys to set sequence 1 to manual mode. You need to set ten sequence
settings for one program. The default setting is SKIP.
[ SEQ 1 ] 1: AUTO
0: SKIP 2: MANUAL
3. Setting the Sequence Load ON/OFF Time
The sequence ON/OFF time controls the Load input ON/OFF when the program’s
sequence is executed. The ON/OFF time range is 0 to 60 seconds. (30S each)
Press 8, ENTER keys to set OFF time for 8 seconds. The default setting is 0 second for
OFF time.
4. Setting the Short Delay/ON Time
The range of short delay and on time is from 0 to 60 Sec. The short delay time starts
from the beginning of the Load on time. If the short time is set to 0 Sec., the Load will
not short. The default setting is 0 Sec.
Press 8, ENTER to set SHORT on time for 8 seconds.
SEQUENCE 1
SHORT DELAY : 0.0 S
SEQUENCE 1
LOAD OFF TIME : 8.0 S
SEQUENCE 1
LOAD ON TIME : 20.0 S
4-11
