High Power DC Electronic Load 63200 Series Quick Start Guide
Note 1 PARALLEL:
Following are the selections of PARALLEL setting functions:
0: NONE: It disables the parallel mode function.
1: MASTER: It sets the Electronic Load as Master (main
control unit.)
When setting the Electronic Load as the main control unit in
the parallel group, only the front panel of Master or direct
command from PC can control it. It not only can operate
simultaneously but also can inform Slave the current for
loading.
2: SLAVE: It sets the Electronic Load to Slave.
3: MASTER SYN: It performs parallel synchronization only. All
Master, Slave loadings need to be inputted
separately but the control movement and
usage mode will be determined by the front
panel on MASTER or PC input for
synchronization.
15
The model 63201 to 63210 can be paralleled for use
interactively, while the 63211 can only be paralleled
with the same model.
PARALLEL = MASTER
PRESS 0 → 3 TO SELECT
PARALLEL = MST SYNC
PRESS 0 → 3 TO SELECT
SLAVE1 OFFLINE
PARALLEL = NONE
PRESS 0 → 3 TO SELECT
