High Power DC Electronic Load 63200 Series Quick Start Guide
Setting CV Values
The CV mode for the Load is programmed by pressing CV. The voltage
values can be programmed in low voltage (CVL) or high voltage (CVH)
range. The current is always in high range. All voltage levels are
programmed in Volt.
Setting CP Values
The CP mode for the Load is programmed by pressing CP. The power
values can be programmed in low current (CPL) or high current (CPH)
range. All power levels are programmed in Walt. The slew rate is in
A/μs.
For detail local operation, please refer to Chapter 4 in
“High Power DC Electronic Load 63200 Series Operation
& Programming Manual.”
3.2 Rear Panel Description
The Mainframe rear panel includes ports of RS-232C, RS485, GPIB, two
remote sense, three BNC connectors, a pair of input terminals, an AC
LINE socket, and a fuse holder. Figure 3-3 to Figure 3-6 shows the rear
panel of Mainframe 63200 Series.
21
