Other Options
fi gure 8.1
Pump Capacity
• Alternate Voltages: 208, 380, 575 VAC, 3 phase
• Expanded Open Loop Cooling: increased cooling water fl ow
• Expanded Closed Loop Cooling: 6.3 sq. ft. heat exchanger
• Solid State Power Control: SCR heater switching
• Surge Reduction valve: reduces water pressure spikes
• Door Interlock: prevents operation with service door open
• Digital Communications: for interface with ChromaSoft or
remote PC/PLC systems
• IEC Style Contactor: for dry contact power switching
• Isolation Valve Kit: 1” ball valve for system isolation
Pump Capacity
PSI
78
69
61
52
43
35
26
17
9
Ft.
180
160
140
120
100
80
60
40
20
020 40 60 80 100 120
U.S. Gallons Per Minute
3/4 HP
1.5 HP
3 HP
5 HP
7.5 HP
