To Next PageTo Next PageWhat to do if CAN1 is not detected on a Chrysler Directed?
Check the CAN1 Tan and Tan/Black wire connections. Wake up the data bus by turning the ignition on and try again. If your installation doesn't need this connection, skip this step by pressing the programming button 5 times.
What to do if Chrysler Car Alarm bypass data is not detected?
Check the connection of the bypass line. If multiple wires are used, ensure they are not inverted. Also, verify that the vehicle still operates correctly with the factory key.
What to do if the Chrysler Directed Car Alarm doesn't detect the ignition?
Check the ignition input connection. The system can detect ignition either from the CAN bus or via a direct wire input.
