Chrysler PACIFICA 2018 - Page 459

Cavity Cartridge Fuse Blade Fuse Description
F75 – 5 Amp Tan Overhead Console /
RR ISC
F76 – 20 Amp Yellow Uconnect/DCSD/
Telematics
F77A – 10 Amp Red RR Entertainment Screen 1
& 2/Media HUB 1 & 2/3rd
Row USB Charge Only/
2nd Row USB Charge
Only/Vaccum Cleaner SW/
3rd Row Recline ST SW/LT
& RT Stow N Go SW/LT &
RT Sliding Door SW Back-
light
F77B – 10 Amp Red Rain Sensor/
Sunroof /CRVMM
F78A – 15 Amp Blue Transmission control Mod-
ule (TCM)/ E-Shifter
F78B – 15 Amp Blue Instrument Cluster
F79 – 10 Amp Red ICS/Front And Rear
HVAC/ SCCM/ EPB
F80 – – Not Used
F81 – – Not Used
7
IN CASE OF EMERGENCY 457
