Cavity Cartridge Fuse Blade Fuse Description
F96 – 10 Amp Red Occupant Restraint Con-
troller (ORC) (Airbag)
F97 – 10 Amp Red Occupant Restraint Con-
troller (ORC) (Airbag)
F98 – 15 Amp Blue Left HID Headlamp
F99 30 Amp Pink – Trailer Tow Module - If
Equipped
F100A – 10 Amp Red AHLM
F100B – 10 Amp Red Rear Camera/LBSS/RBSS/
CVPM/Humidity
Sensor/In Vehicle Tempera-
ture Sensor
Circuit Breakers
CB1 25 Amp Power Seats (Driver)
CB2 25 Amp * Power Seats (Pass)
CB3 25 Amp FRT PWR Window W/O
Door Nodes + RR PWR
Window Lockout
* 30A mini fuse is substituted for 25A Circuit Breaker.
7
