inward on each travel stop, and pull the glove compart-
ment door down until the travel stops pass clear of their
hooking points.
4. Open the glove compartment door as far as possible to
gain access to the cabin air filter compartment cover.
5. Pry up the lid of each individual compartment snap,
and detach it from the rest of the snap. There is a small
space on the side of each snap to use for separating the
lid from the snap. Once detached, remove the rest of the
snap completely from the compartment cover.
6. After removing the snaps, lift up the compartment cover
to gain access to the fresh air inlet.
7. Remove the filter cover by prying back each of the
retaining tabs from their hooking points, and then
Cabin Air Filter Compartment Cover
1 — Compartment Cover
2 — Compartment Snap
Fresh Air Inlet
1 — Filter Cover
2 — Retaining Tab
516 SERVICING AND MAINTENANCE
