RECEIVER TEST CONNECTOR FOR STC 95 INSTRUMENT
Term
Symbol
Function
1
S
Alarm threshold ( 0,3  9 V )
2
ALL
Alarm signal
3
S
Detected signal
4
0,2
Amplify signal ( 200 mVpp )
5
+
Power Supply Output 13,8 V
6
-
Ground
7
V Rag
AGC (Automatic Gain Control) Voltage
RECEIVER LEDS
N°
Symbol
Function
Default
1
Channel
Channel Ok
ON
2
Alarm
Alarm
ON
3
Main
Power On
ON
RECEIVER TRIMMERS
N°
Symbol
Function
1
SEN
Sensitivity setting Trimmer ( Minimum – anticlock wise )
2
INT
Integration setting Trimmer ( Minimum – anticlock wise )
RECEIVER CHANNELS SWITCH
N°
Symbol
Function
1
DS 1
Channel Selector ( 1  4 )
RECEIVER FUSES
N°
Symbol
Function
1
F 1
Power supply protection fuse battery 13,8 V
