 CIAS Elettronica S.r.l. Ed. 2.2
Installation Handbook page 43 to 43 ERMO 482
6. CHARACTERISTICS
6.1 Technical characteristics
TECHNICAL CHARACTERISTICS
Min
Nom
Max
Note
Frequency
9,47 GHz to 10.60 GHz
According with national rules
Maximum Power to emitting
20 to 500 mW e.i.r.p.
According with national rules
Modulation
On / Off
Duty-cycle
50 / 50
Channel number
4
RANGE:
ERMO 482 / 50
50 m
ERMO 482 / 80
80 m
ERMO 482 / 120
120 m
ERMO 482 / 200
200 m
DC Power Supply ( V~ ):
17 V~
19 V~
21 V~
DC Power Supply (V ):
11,5 V
13,8 V
14,8 V
Max. Current absorption TX (mA ~)
158 mA
Max. Current absorption RX in Surveillance
(mA ~)
130 mA
Max. Current absorption RX in Alarm (mA ~)
120 mA
Max. Current absorption TX (mA )
50 mA
Max. Current absorption RX in Surveillance
(mA )
38 mA
Max. Current absorption RX in Alarm (mA )
32 mA
Intrusion Alarm contact (RX) (N.C.)
100 mA
120 mA
Radome removal contact and out of position
(TX RX)
100 mA
LEDS
Power Supply presence (TX) Green LED
On
Channel identification (RX) Green LED
On
Non intrusion Alarm status (RX) Green LED
On
Sensitivity tuning (RX)
Trimmer
Integration tuning (RX)
Trimmer
Weight without battery (TX)
2910 g
Weight without battery (RX)
2970 g
Diameter
305 mm
Depth with jaw
280 mm
Operating Temperature
- 25 °C
+ 55 °C
Performance Level
3°
Box Protection level
IP 55
