6. CHARACTERISTICS
6.1 Technical characteristics
TECHNICAL CARACTERISTICS Min Nom Max Note
Frequency F1 10.58 GHz -
Frequency F2 9.9 GHz
Frequency F3 9.46 GHz
Frequency F4 10.525 GHz
Maximum power 20mW 500 mW e.i.r.p.
Modulation - - - on/off
Duty-cycle - 50/50 - -
Number of channels - - 16 -
Range:
MANTA/50 - 50 m - -
MANTA/80 - 80 m - -
Power supply ( V ) 11,5 V 13,8 V 16 V -
Current absorption TX in surveillance ( mA ) - 80 - -
Current absorption TX in alarm ( mA ) - 50 - -
Current absorption RX in surveillance ( mA ) - 58 - -
Current absorption RX in alarm ( mA ) - 55 - -
Intrusion alarm contact (RX) - - 100mA C-NC
Radome removal contact (TX+RX) - - 100mA C-NC
Fault contact (TX+RX) - - 100mA C-NC
Intrusion alarm (RX) Red LED OFF - - - Not active
Radome removal (TX+RX) Red LED OFF - - - Not active
Fault alarm (TX+RX) Red LED OFF - Not active
Thresholds adjustment - - - On board +
SW
Weight without battery (TX) - 800 g - -
Weight without battery (RX) - 800 g - -
Diameter 205x160 mm -
Deep, brackets included 200 mm -
Working temperature -25 °C - +55 °C -
Performance level 3° -
Box protection level IP55 -
