2. INSTALLATION
2.1 Initial Information
Measure the length of the perimeter to be protected. It is then possible to calculate how many
Sioux-CU will be required. Each Sioux-CU system can protect up to 700m.
Decide on the mounting distance between sensors.
This is necessary to calculate the number of Sioux-Master and Sioux-Slave that will be required
and the lengths of the sensor interconnecting cables. The cables can have a length of 3, 5 or
10m and it is resistant to UV and weather.
The sum of the length of each line (LINE1 or LINE2), which includes pre-wired cable made by
CIAS plus LEAD CABLE (not pre-wired cable for connections between sensors), must not
exceed 400 meters. Refer to the following table.
