3.2.1.1 Automatic assignment of the device numbers
During this procedure device numbers of the various Sioux-Master devices connected to the two
serial lines LINE1 and LINE2 will be automatically assigned.
Starting from the closest Sioux-Master device on both lines they will be assigned device numbers
4, 11, 18, 25, 32, 39, 46, 53,60, 67.
Once the device number assignment is finished the position of the Sioux-CU will be read and
stored (Reference Position).
Any subsequent change in this Sioux-CU position will generate a tamper.
The buzzer emits 3 short beeps duration if the procedure is completed correctly.
Otherwise it will emit a sound of 2 seconds duration.
This signifies that at least one of the master boards present in the configuration has not been
assigned a device number.
At the end of the procedure return the Sioux-CU to normal operation (function 0)
3.2.1.2 Allocation of the Sioux-CU number
Position the decimal switches (tens and units) so that they make up the number to be assigned to
the Sioux-CU. Push the SET BUTTON to acquire the value.
3.2.1.3 Manual assignment of the device numbers
To manually assign the device number for a master board it is necessary to position the function
switch on 3 if the master board is found on the left branch or on 4 if it is found on the right branch.
Set the tens and units switches to the device number to be assigned. Push the SET BUTTON to
assign the value.
At this point the master board device number is set.
When the allocation is complete the Sioux-CU buzzer emits one short beep.
Setting the value 00 on the tens and units switches and pushing the SET BUTTON will cause the
Sioux-CU to delete the device numbers of all the Sioux-master boards on the selected branch.
