3.2.1.4 Touch and zone
To activate the “Touch and Zone” position the function switch on 5 and push then SET BUTTON.
Take care that the configured sensors number is equal to the sensors connected to Sioux CU.
If after the last master on a branch there aren’t 3 slave sensors, modify the sensors number of
that branch. See paragraphs 3.2.1.5 e 3.2.1.6.
Now it’s possible to modify the zones dimension hitting the sensors in way to generate a strong
signal.
− The first hit identifies the beginning of the first zone and it must be equal with the last
configured sensor on the left branch. The other hits identify the zone’s end.
− Now the sensor that receive the second hit become the last of the first zone, the sensor
that receive the third hit become the last of the second zone, etc.
− The maximum number of the zones is 20.
The “touch and zone” procedure finishes when the 20th zone is located or when the configured
sensor on the right will be hit.
The 20th zone, if present, ends always with the right sensor in the configuration.
When a sensor is hit the buzzer emits an acoustic signal in this way:
− the first hit that identifies the beginning of the first zone permits to emit 2 short beep
− the hit that identify the end of the zone permits to emit 1 short beep
− the hit that ends the procedure permits to emit 2 long beep
− if a sensor that it’s on the left of the last hit sensor is hit and this sensor belongs to the
same zone of the other sensor, the zone dimension is reduced and 3 short beep will be
emitted
− if a sensor on a previous zone of the last hit sensor is hit, an error signal will be emitted
In this case it’s possible to proceed how this last sensor is not hit.
At the end of the procedure the new configuration will be saved in Sioux CU
3.2.1.5 Change of the left branch sensor number
To modify the left branch sensor number position the function switch on 6 and the switches tens
and unit in way to form the number of sensors that you want to assign to the left branch. Push
then the SET BUTTON
3.2.1.6 Change of the right branch sensor number
To modify the right branch sensor number position the function switch on 7 and the switches tens
and unit in way to form the number of sensors that you want to assign to the right branch. Push
then the SET BUTTON
3.2.1.7 Store Cut Prealarm Events and Signals
It is possible to set if store or not Cut Prealarm Events in the Event Log and Monitor files of the
CU
To access this setting select position 8 by the “function” selector.
- Selecting by the tens and unit selectors values 0 and 0 and pushing SET BUTTON, the
store function for Cut Prealarm Event is DISABLED
- Selecting by the tens and unit selectors values respectively 0 and 1 and pushing SET
BUTTON, the store function for Cut Prealarm events is ENABLED.
