2.4.4 - Use
Action Description
Start-up/shutdown
From the home screen, press
and conrm
Fault acknowledgement
Press the alarm icon in the menu bar
and conrm with
Status: machine shut down
red
Status: machine on
green
Status: run request with the unit shut down
red/green ashing
Accessing the parameters
In each parameters table, it is possible to scroll down the table using your nger.
In the setpoint or setting parameters table, it is possible to modify a value by pressing on it. A numeric pad will open, indicating the
possible setting range (min. and max.), and this must be conrmed via
It is possible to search for a parameter using its number. To do so, press the icon in the menu bar. Enter the parameter number,
and conrm with
. If the parameter exists and your access level is sucient, you will be automatically redirected to the page
containing this parameter. Otherwise, an error message will be displayed.
Overview
The home screen shows an overview of the operation of the machine. Only the components present in the machine are visible.
Return or room air
temperature
Supply air temperature
Duct pressure
Extraction ow
Intake ow
Fresh air temperature
Press on each component to access the corresponding reading parameters.
A ring positioned beside each component indicates its status:
- Grey: : inactive
- Green: in operation
- Orange: maintenance fault
- Red: danger fault
2 - THE CONTROL PLC
FLOWAY ACCESS EN-12
