CIAT FLOWAY ACCESS User Manual

No, Description
Setting
Unit Display conditions
Access
level
Enumeration By default
270
Temperature setpoint compensation
activation
0: None
1: With
0 2
270,1 Heating compensation start fresh air temp. 10,0 °C P270 = With 2
270,2 Heating compensation end fresh air temp. -20.0 °C P270 = With 2
270,3
Heating compensation max. setpoint
difference
3,0 °C P270 = With 2
270,5 Cooling compensation start fresh air temp. 25,0 °C P270 = With 2
270,6 Cooling compensation end fresh air temp. 40,0 °C P270 = With 2
270,7
Cooling compensation max. setpoint
difference
2,0 °C P270 = With 2
271 Downgraded fresh air ow rate activation
0: None
1: With
0 2
271,1 Downgraded mode start fresh air temperature 10,0 °C P271 = With 2
271,2 Downgraded mode end fresh air temperature -20.0 °C P271 = With 2
271,3 % min. ow rate in downgraded mode 30,0 % P271 = With 2
280 Fire safety operating mode
0: off
0
P24 = with
2
1: Intake forced /
exhaust shut down
2: Exhaust forced /
intake shut down
3: Intake and exhaust
forced
P24 = with and P104 = ow rate control
282 Intake ow rate in case of re 10000 m
3
/h P280 = 1 or 3 2
283 Exhaust ow rate in case of re 10000 m
3
/h P280 = 2 or 3 2
286 DX unit defrosting management
0: None
1: Derated mode
2: AHU shut down
0
P28 = Cooling direct expansion or heating direct
expansion or reversible direct expansion
2
287
Intake pressure setpoint during DX unit
defrosting
100 Pa P286 = Derated mode and P104 = duct pressure 2
288
Intake ow rate setpoint during DX unit
defrosting
As per P1 m
3
/h P286 = Derated mode and P104 = ow rate 2
289
Exhaust ow rate setpoint during DX unit
defrosting
As per P1 m
3
/h P286 = Derated mode and P104 = ow rate 2
292 FMA warning on fault output
0 : No
1 : Yes
1 2
293 FMA warning on CMS
0 : No
1 : Yes
1 2
9 - PARAMETERS
FLOWAY ACCESS EN-54
