EN - 11
B- Closed circuit - Underground loop or geothermal loop
Note: the schematic diagrams herein are provided for information only. Under no circumstances do they constitute actual
installation diagrams.
Hydraulic hoses
20% or 40% MPG (monopropylene glycol)
Buried glycol
solution loop
Filler material
Geothermal sensor
Return
circuit
Supply circuit
Shut-off valves
Thermometer pockets
Mandatory safety valve
Mandatory
safety valve
Screen filter
Screen filter
A
B
A
B
INDOOR
CIRCUIT
Filling
kit
(option)
