EN - 31
Heating setpoint (UHCS water return temperature in °C)
P112P111
Preheating Heating
Duration (days)
P154
20°C
Compliance with
DTU 65.14
3.4 Activating the underfloor heating system
Like the air bleed function, the GeoCIAT
TM
Modular is equipped with an automatic function which, when the heat pump is not
paired, prepares to activate the underfloor heating system by electrically connecting the heat pump to the electrical network.
If the heat pump has been paired and the underfloor heating system has not been activated, a manual request can be issued
as follows:
- Select the UHCS heating sequence in the Unit configuration sub-menu,
- Only installers with level 2 or 3 access may enter this machine configuration mode.
This function is only accessible if parameter P07=UHCS and if the unit is off.
In the UNIT CONFIGURATION menu,
select
System start-up then confirm with
CLIC
The display below appears.
unit parameter
YeS
Where:
P111: Tile preheating period. Adjustable from 3 to 7 days in 1 day increments. Default value = 3 days.
P112: Heating period. Adjustable from 4 to 7 days in 1 day increments. Default value = 4 days
Temperature rise with a setpoint increase of 1°C every 4 hours,
Maximum operating temperature maintained.
P154: Maximum operating setpoint. Adjustable from 20 to 40°C in 0.5°C increments. Default value = 35°C
The time remaining for the sequence is displayed on the home screen for information. At the end of the sequence, the unit operates
using the tile preheating setpoint (P110) for safety reasons. The home screen then displays the text END OF SEQUENCE.
TUESDAY 19 JANUARY
14:58
end of SeQuence
