74
Low Fluorescence value:
Fo - dark, Fs - ambient
High Fluorescence value:
Fm dark, Fms - ambient
Ratio of DHL:H:
Fv/Fm - dark, Y - ambient
The Ratio is the only value that is not in A/D counts. It should be interpreted as 0.xxx
where xxx is the number displayed in the table. For example: if the number displayed is
99, the ratio is 0.099.
The default saturation pulse length is 1 second.
Figure F-1. CI-510CF CHLOROPHYLL FLUORESCENCE MODULE
SPECIFICATIONS:
Power:
10 to 30 VDC, 75mA (175mA during
saturation pulse)
Fuse:
0.5A FB 3AG
