CIGWELD weldskill 135 - Attaching the Euro Style Connection Weldskill 150 MIG Torch

WELDSKILL 100, 135, 150 MIG
3-5
Installation
3.09 Attaching the Euro Style Connection WeldSkill 150 MIG Torch.
Fit the MIG Torch to the Power Source by pushing the torch connector into the (A) Mig torch adaptor and
screwing the plastic torch collar clockwise to secure the Mig torch to the Mig torch adaptor. To remove the
Mig Torch simply reverse these directions.
50
Portable Welding Machine
MI G
OVERHEAT
WIRESPEED
OUTPUT VOLTAGE
(Do not switch while welding)
CONTROL
ON
OFF
4
2
3
1
OFF
(A) MIG Torch Adaptor
(Euro Style)
Work Cable Socket (Dinse™)
Art # A-09009
Figure 3-5 Attaching Mig Torch
