CIGWELD weldskill 135 - Setup for WeldSkill 100 MIG

WELDSKILL 100, 135, 150 MIG
3-13
Installation
3.17 Setup For WeldSkill 100 MIG
!
WARNING
Before connecting the work clamp to the work and inserting the electrode wire into the Mig Torch
make sure the Mains power supply is switched off.
CAUTION
Remove any packaging material prior to use. Do not block the air vents at the front or rear of the
Welding Power Source.
NOTE
Suitable for Gasless Mig Wire only. Refer to the set up guide located on the inside of the wirefeed
compartment door.
WORK
WORK CLAMP
ARC
240V AC POWER SOURCE
Art # A-09017
Figure 3-13: Set-up for WeldSkill 100 Mig
