7. Check Control Messages
The check-control messages are divided into two groups:
1. Messages in explicit mode: place over the dispensing keys. They are cancelled on each new cycle and then appear again if
the cause that generated them returns
2. Messages in code: these appear in the top right-hand corner with the following syntax:i: Exxx
where:
·E indicates an error;
·xxx rappresents the error code of the unit.
When there are several errors, their representation is timed, passing in succession on the display.
)RUPRUHGHWDLOVSOHDVHFRQVXOWWKHWHFKQLFDOPDQXDODWWKH&RQ¿JXUDWLRQPHQX'HIHFW0DOIXQFWLRQV
Messages in explicit mode
MESSAGE
Machine cold
No coffee
(MM...)
Grounds
drawer full
Empy drawer
Grounds
drawer
removed
%RLOHU¿OOLQJ
Service
needed
No milk
VERIFICATIONS
2. Consult the technical manual and refer to the
VSHFL¿FHUURUFRGHZKLFKZLOOEHÀDVKHGRQWKH
display to solve the problem
Fill in the hopper with coffee beans.
Empty the drawer to reset the counter or wait
until when the machine will display the mes-
sage ‘empty drawer’.
Consult the technical manual to program the
number of grounds to the attainment of which
the message will be visualized.
Remove the coffee grounds drawer.
Empty the drawer and replace it in the cor-
rect position. Close the panel. During this
operation the message ‘Groun. Draw. Re-
moved’ will be displayed.
If this message appears when the drawer is
inserted, check the drawer is correctly posi-
tioned.
This operation is performed automatically
and requires no action by the user.
This operation does not impede the hot water
delivery.
Contact the authorized technical department.
The message will be displayed until the serv-
ice will be carried out. (Refer to the Techni-
cian’s Manual).
5H¿OOLQWKHUHIULJHUDWRUWDQN
POSSIBLE CAUSES: when the message is visualized
1. This message will appear on the display every time the ma-
chine is turned on until the service boiler pressure falls below the
pre-set working pressure. When the service boiler reaches the
pre-set pressure, the message automatically disappears.
2. Whether the service boiler cannot reach the set working pres-
sure because of a problem, this message will be integrated with
the message in code identifying the component that caused
that problem.
One or all hoppers are almost empty.
This message means that the coffee ground drawer is full.
10 more coffee selections (or 5 double dose) may be made
(coffee-based drinks) before the machine is blocked and the
following message is then displayed.
The machine counts in decreasing order the pre-set maximum
grounds number. This message means that that value run out.
The machine is blocked and no coffees beverages can be de-
livered.
This message always appears when the back side of the
drawer is not in the right position.
7KLVPHVVDJHLVGLVSOD\HGZKHQWKHPDFKLQHLV¿OOLQJWKH
boiler
This message is displayed when the machine requires the peri-
odic maintenance intervention. In order to eliminate temporary the
message, keep pressed RES key for approximately 8 seconds.
The message will reappears in the successive relighting of the
machine with the main switch.
The message is displayed only if the machine is connected to
a ‘Fresh Milk’ and indicates that there is no milk in the refrig-
erator tank.
