RGU-10 B, RGU-10 B RCM
Instruction Manual
6. TECHNICAL FEATURES
Power supply AC
(1)
Rated voltage 230 V ~ ± 20%
Frequency 50 - 60 Hz
Consumption 6 VA
Installation category CAT III 300 V
Power supply DC
(1)
Rated voltage
24 ... 125 V ± 20%
Consumption 4 W
CInstallation category CAT III 300 V
(1)
Depending on model
Monitoring features
Sensitivity 0.1, 0.3, 0.5, 1, 3 A
Tripping delay 0.1, 0.2, 0.3, 0.4, 0.5, 0.75, 1, 5, 10 s
Relay output
Quantity 2
Type Electronic class B
Rated voltage 250 V ~
Maximum switching voltage 400 V ~
Rated current 10 A ~
Instantaneous maximum current 15 A ~
Rated load in AC1 2500 VA
External trip / Reclose input
Type Optocoupled
Maximum voltage 230 V ± 20% ~
Maximum consumption 0.7 W
Type of transformer to use
Sensitivity (In) Transformer
≥ 100 mA WGS-20 TB, WGC-25 TB, WGC-35 TB
≥ 300 mA WGC-55 TB
≥ 500 mA WGC-80 TB, WGC-110 TB, WGC-140 TB, WGC-180 TB
Alarm range according to leakage current measured
Current Lower limit Upper limit
Type AC (sine)
0.8 x Idn
1 x Idn
Type A
Sine half wave
1.4 x Idn
Sin half wave phase controlled (90º- 135º)
Type B
Smooth DC current 1.7 x Idn
Sine current at 150 Hz
1 x Idn
Sine current at 400 Hz
Sine current at 1000 Hz 1 x Idn 1.3 x Idn
User interface
Display LCD
Keyboard 7 keys
LED 2 LEDs
