Cirrus SR22 - Page 418

4 of 10 P/N 13772-145
Section 9 Cirrus Design
Supplements SR22 / SR22T
Figure - 1
Placards
Serials 0002 thru 2333,
2335 thru 2419, 2421 thru 2437.
Serials 2334, 2420, 2438 & subs.
EM_SR22_FM02_3181
REFERIRSE AL POH PARA LOS LUBRICANTES APROBADOS
ABOVE 40°F SAE 50, 20W50 OR 20W60
BELOW 40°F SAE 30, 10W30, 15W50 OR 20W50
CUALIDADES DEL ACEITE DE MOTOR
POR DEBAJO DE 4°C (40°F) SAE 30, 10W30, 15W50 O 20W50
POR ARRIBA DE LOS 4°C (40°F) SAE 50, 20W50 O 20W60
REFER TO AFM FOR APPROVED OILS
ENGINE OIL GRADE
4 PLC'S
2 PLC'S
2 PLC'S
2 PLC'S
3 PLC'S
Exterior Placards
Original Issue: 09-30-09
