Cirrus SR22 - Page 447

P/N 13772-149 3 of 10
Cirrus Design Section 9
SR22 / SR22T Supplements
Placards
Serials 22-0002 thru 22-2437.
AVGAS GRADO MIN 100LL O 100
40.5 EE.UU.GALS. (153 LITROS) CAPACIDAD TOTAL UTLIZABLE
23.5 EE.UU. GALS. (89 LITROS) UTLIZABLE APENDICE METALICO
EM_SR22_FM09_3544
4 PLC'S
2 PLC'S
2 PLC'S
2 PLC'S
3 PLC'S
REFERIRSE AL MVA PARA LOS LUBRICANTES APROBADOS
ABOVE 40°F SAE 50 OR 20W50
BELOW 40°F SAE 30, 10W30, 15W50 OR 20W50
CALIDADES DE ACEITE PARA MOTOR
DEBAJO 40°F (4°C) SAE 30, 10W30, 15W50, O 20W50
SOBRE 40°F (4°C) SAE 50 O 20W50
REFER TO AFM FOR APPROVED OILS
ENGINE OIL GRADE
Serials 22-2438 & subs,
22T-0001 & subs.
AVGAS MIN GRADE 100LL OR 100
40.5 U.S.GALS. (153 LITERS) TOTAL USABLE CAP.
23.5 U.S.GALS. (89 LITROS) USABLE TO TAB
AVGAS GRADO MIN 100LL O 100
46 EE.UU.GALS. (174 LITROS) CAPACIDAD TOTAL UTLIZABLE
30 EE.UU. GALS. (114 LITROS) UTLIZABLE APENDICE METALICO
2 PLC'S
Figure - 1
Exterior Placards
Original Issue: January 14, 2013
