PoE LED2GE WAN Ports: 0-7
(0,2,4,6 at the top and
1,3,5,7 at the bottom)
1
GE0 LED4GE1 LED3
RJ-45 Console LED6USB LED5
Micro USB Console LED8USB Console7
DSL10CD LED9
DATA LED11
The following table summarizes the LED indicators that are located in the bezel or chassis of the C111x series.
Table 2: LED Indicators for C111x
Control SourceDescriptionLED ColorPort
Bezel sideIlluminated Cisco logo.
Indicates router power is
good.
BlueCisco Logo
Bezel side. All models.Steady Green - System
operates normally.
Green and AmberSTATUS
(System Status)
Off—System is not out of
reset or BIOS image is not
loadable.
Blinking Amber —
BIOS/Rommon is
booting.
Steady Amber —
BIOS/Rommon has
completed booting, and
the system is at the
Rommon prompt or
booting the platform
software.
Bezel sideOff—No tunnel.Green
VPN OK
Steady On— At least one
tunnel is up.
Hardware Installation Guide for the Cisco 1000 Series Integrated Services Router
8
Overview of Cisco 1000 Series Integrated Services Routers
LED Indicators
