Cisco 3900 Series, Cisco 2900 Series, and Cisco 1900 Series Integrated Services Routers Generation 2 Software Configuration Guide
Chapter Configuring Ethernet CFM and Y.1731 Performance Monitoring on Layer 3 Interfaces
CFM Support on Routed Port and Port MEP
Configuring Ethernet CFM (Single-Tagged Packets)
Complete these steps to configure and enable Ethernet CFM for single-tagged packets:
SUMMARY STEPS
Step 1 enable
Step 2 configure terminal
Step 3 ethernet cfm ieee
Step 4 ethernet cfm global
Step 5 ethernet cfm domain domain-name level level-id
Step 6 service service-name vlan vlan-id direction down
Step 7 continuity-check
Step 8 interface gigabitethernet slot/port
Step 9 ethernet cfm mep domain domain-name mpid value service service-name
Step 10 interface gigabitethernet slot/port.subinterface
Step 11 encapsulation dot1q vlan-id
Step 12 end
DETAILED STEPS
Command Purpose
Step 1
enable
Example:
Router>enable
Enables the privileged EXEC mode.
Enter your password when prompted.
Step 2
configure terminal
Example:
Router#configure terminal
Enters the global configuration mode.
Step 3
ethernet cfm ieee
Example:
Router(config)#ethernet cfm ieee
Enables the IEEE version of CFM.
Step 4
ethernet cfm global
Example:
Router(config)#ethernet cfm global
Enables CFM processing globally on the router.

Cisco 1941 Specifications

General

Product Type	Router
Product Series	1900
Model	1941
Connectivity Technology	Wired
Data Link Protocol	Ethernet, Fast Ethernet, Gigabit Ethernet
Flash Memory	256 MB
Power Supply	Internal power supply
Power	AC 120/230 V (50/60 Hz)
Operating System	Cisco IOS
Product Name	Cisco 1941
Form Factor	Rack-mountable
Network/Transport Protocol	IPSec, L2TP, PPPoE, PPPoA
Remote Management Protocol	SNMP, Telnet, SSH, HTTP, HTTPS
Features	Firewall protection, VPN support, VLAN support
Interfaces	2 x 10/100/1000Base-T Ethernet WAN, 2 x USB 2.0
Expansion Slots	2 x EHWIC 1 x ISM slot
Wireless LAN	No
RAM	512 MB (installed) / 768 MB (max)
