Cisco 3900 Series, Cisco 2900 Series, and Cisco 1900 Series Integrated Services Routers Generation 2 Software Configuration Guide
Chapter Configuring Ethernet Virtual Connection Bridge Domain
Connectivity Fault Management (CFM) over EVC BD
Configuring and Enabling the Cross-Check Function (CE-B)
SUMMARY STEPS
Step 1 enable
Step 2 configure terminal
Step 3 ethernet cfm domain domain-name level level-id
Step 4 mep mpid mpid
Step 5 exit
Step 6 ethernet cfm mep crosscheck start-delay delay
Step 7 exit
Step 8 ethernet cfm mep crosscheck {enable | disable} domain domain-name] {port | vlan {vlan-id | vlan-id
- vlan-id | , vlan-id - vlan-id}}
DETAILED STEPS
Step 7
exit
Example:
Router(config)# exit
Returns the device to privileged EXEC mode.
Step 8
ethernet cfm mep crosscheck {enable |
disable} domain domain-name] {port |
vlan {vlan-id | vlan-id - vlan-id | ,
vlan-id - vlan-id}}
Example:
Router# ethernet cfm mep crosscheck
enable domain cust4 vlan 100
Enables cross-checking between the list of configured
remote MEPs of a domain and MEPs learned through
CCMs.
Command Purpose
Command Purpose
Step 1
enable
Example:
Router>enable
Enables the privileged EXEC mode.
Enter your password when prompted.
Step 2
configure terminal
Example:
Router# configure terminal
Enters the global configuration mode.

Cisco 1941 Specifications

General

Product Type	Router
Product Series	1900
Model	1941
Connectivity Technology	Wired
Data Link Protocol	Ethernet, Fast Ethernet, Gigabit Ethernet
Flash Memory	256 MB
Power Supply	Internal power supply
Power	AC 120/230 V (50/60 Hz)
Operating System	Cisco IOS
Product Name	Cisco 1941
Form Factor	Rack-mountable
Network/Transport Protocol	IPSec, L2TP, PPPoE, PPPoA
Remote Management Protocol	SNMP, Telnet, SSH, HTTP, HTTPS
Features	Firewall protection, VPN support, VLAN support
Interfaces	2 x 10/100/1000Base-T Ethernet WAN, 2 x USB 2.0
Expansion Slots	2 x EHWIC 1 x ISM slot
Wireless LAN	No
RAM	512 MB (installed) / 768 MB (max)
