connections to your LAN, WAN, and console terminal.
Chapter 4, "Configuring the Cisco Multiport Serial Routers," discusses configuring the terminal
and modems and other asynchronous devices attached to the multiport routers manually using
configuration mode, using AutoInstall, or manually using the setup facility.
●
Appendix A, "Troubleshooting the Router," discusses how to isolate problems and read the LEDs.●
Appendix B, "Maintaining the Router," discusses selected maintenance procedures.●
Appendix C, "Cable Specifications," provides pinouts for the router ports and cables.●
Conventions
This publication uses the following conventions to convey instructions and information.
Command descriptions use these conventions:
Commands and keywords are in boldface font.
●
Variables for which you supply values are in italic font.●
Elements in square brackets ([ ]) are optional.●
Alternative but required keywords are grouped in braces ({ }) and are separated by vertical bars ( |
).
●
Examples use these conventions:
Terminal sessions and information the system displays are in screen font.
●
Information you enter is in boldface screen font.●
Nonprinting characters are in angle brackets (< >).●
Default responses to system prompts are in square brackets ([ ]).●
Note Means reader take note. Notes contain helpful suggestions or references to materials not contained
in this manual.
Time Saver Means the described action saves time. You can save time by performing the action
described in the paragraph.
Caution Means reader be careful. In this situation, you might do something that could result in
equipment damage or loss of data.
Warning This warning symbol means danger. You are in a situation that could cause bodily
injury. Before you work on any equipment, you must be aware of the hazards involved with
electrical circuitry and familiar with standard practices for preventing accidents. (To see translated
versions of this warning, refer to the "Regulatory Compliance and Safety Information" document
that accompanied the router.)
Copyright 1989-1997 © Cisco Systems Inc.
