Cisco 3900 Series, Cisco 2900 Series, and Cisco 1900 Series Integrated Services Routers Generation 2 Software Configuration Guide
OL-20696-04
Chapter Configuring Backup Data Lines and Remote Management
Configuring Dial Backup and Remote Management Through the Console Port or Auxiliary Port
Step 11
ip route prefix mask {ip-address | interface-type
interface-number [ip-address]}
Example:
Router(config)# ip route 0.0.0.0 0.0.0.0 22.0.0.2
Router(config)#
Sets the IP route to point to the dialer
interface as a default gateway.
Step 12
access-list access-list-number {deny | permit} source
[source-wildcard]
Example:
Router(config)# access-list 1 permit 192.168.0.0
0.0.255.255 any
Defines an extended access list that
indicates which addresses need
translation.
Step 13
dialerwatch-list group-number {ip ip-address
address-mask | delay route-check initial seconds}
Example:
Router(config)# dialer watch-list 1 ip 22.0.0.2
255.255.255.255
Router(config)#
Evaluates the status of the primary link,
based on the existence of routes to the
peer. The address 22.0.0.2 is the peer IP
address of the ISP.
Step 14
line [aux | console | tty | vty] line-number
[ending-line-number]
Example:
Router(config)# line console 0
Router(config-line)#
Enters configuration mode for the line
interface.
Step 15
modem enable
Example:
Router(config-line)# modem enable
Router(config-line)#
Switches the port from console port to
auxiliary port function.
Step 16
exit
Example:
Router(config-line)# exit
Router(config)#
Exits interface configuration mode.
Command Purpose

Cisco 2911 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.1Q, IEEE 802.1ag, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3ah, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
DHCP client	-
Routing protocols	BGP, EIGRP, OSPF
Supported protocols	IPv4, IPv6, IS-IS, IGMPv3, PIM SM, SSM, DVMRP, IPSec, GRE, BVD, MPLS, L2TPv3, PPP, MLPPP, MLFR, HDLC, RS-232, RS-449, X.21, V.35, EIA-530, PPPoE, ATM
USB version	2.0
RS-232 ports	1
Expansion slots	4 x EHWIC 2 x DSP 1 x ISM
USB ports quantity	2
Ethernet LAN (RJ-45) ports	3
Firewall security	Cisco IOS
Input current	2.2 A
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	47 - 63 Hz
Power consumption (typical)	50 W
Product color	Black
Rack capacity	2U
Operating altitude	0 - 4000 m
Non-operating altitude	0 - 4570 m
Storage temperature (T-T)	-40 - 80 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 85 %
Safety	UL 60950-1, CAN/CSA C22.2 No. 60950-1, EN 60950-1, AS/NZS 60950-1, IEC 60950-1
Electromagnetic compatibility	47 CFR, ICES-003, EN55022, CISPR22, AS/NZS 3548, VCCI V-3, EN 300-386, EN 61000, EN 55024, CISPR 24EN50082-1

Weight and Dimensions

Depth	304.8 mm
Width	438.2 mm
Height	88.9 mm
Weight	8200 g
