Cisco 3900 Series, Cisco 2900 Series, and Cisco 1900 Series Integrated Services Routers Generation 2 Software Configuration Guide
Chapter Configuring Ethernet CFM and Y.1731 Performance Monitoring on Layer 3 Interfaces
CFM Support on Routed Port and Port MEP
Configuration Example for Ethernet CFM (Single-Tagged Packets)
This example shows how to configure Ethernet CFM for single-tagged packets:
Step 5
ethernet cfm domain domain-name level
value
Example:
Router(config)#ethernet cfm domain
customer level 7
Defines a CFM maintenance domain at a specified level,
and enters the Ethernet CFM configuration mode.
level can be any value from 0 to 7.
Step 6
service service-name vlan vlan-id
direction down
Example:
Router(config-ecfm)#service
customer1101 vlan 100 direction down
Enters the CFM service configuration mode.
vlan—Specifies the VLAN.
Step 7
continuity-check
Example:
Router(config-ecfm-srv)#continuity-ch
eck
Enables sending continuity check messages.
Step 8
interface gigabitethernet slot/port
Example:
Router(config-ecfm-srv)#interface
gigabitethernet 0/2
Specifies an interface and enters the interface
configuration mode.
Step 9
ethernet cfm mep domain domain-name
mpid mpid-value service service-name
Example:
Router(config-if)#ethernet cfm mep
domain customer mpid 100 service
customer1101
Sets a port to a maintenance domain and defines it as an
MEP.
Note The values for domain and service must be the
same as the values that were configured for CFM.
Step 10
interface gigabitethernet
slot/port.subinterface
Example:
Router(config-if-ecfm-mep)#interface
gigabitethernet 0/2.1
Specifies a subinterface and enters the subinterface
configuration mode.
Step 11
encapsulation dot1q vlan-id
Example:
Router(config-subif)#encapsulation
dot1q 100
Defines the encapsulation format as IEEE 802.1Q
(dot1q), and specifies the VLAN identifier.
Step 12
end
Example:
Router(config-subif)#end
Returns the router to the privileged EXEC mode.
Command Purpose

Cisco 2911 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.1Q, IEEE 802.1ag, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3ah, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
DHCP client	-
Routing protocols	BGP, EIGRP, OSPF
Supported protocols	IPv4, IPv6, IS-IS, IGMPv3, PIM SM, SSM, DVMRP, IPSec, GRE, BVD, MPLS, L2TPv3, PPP, MLPPP, MLFR, HDLC, RS-232, RS-449, X.21, V.35, EIA-530, PPPoE, ATM
USB version	2.0
RS-232 ports	1
Expansion slots	4 x EHWIC 2 x DSP 1 x ISM
USB ports quantity	2
Ethernet LAN (RJ-45) ports	3
Firewall security	Cisco IOS
Input current	2.2 A
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	47 - 63 Hz
Power consumption (typical)	50 W
Product color	Black
Rack capacity	2U
Operating altitude	0 - 4000 m
Non-operating altitude	0 - 4570 m
Storage temperature (T-T)	-40 - 80 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 85 %
Safety	UL 60950-1, CAN/CSA C22.2 No. 60950-1, EN 60950-1, AS/NZS 60950-1, IEC 60950-1
Electromagnetic compatibility	47 CFR, ICES-003, EN55022, CISPR22, AS/NZS 3548, VCCI V-3, EN 300-386, EN 61000, EN 55024, CISPR 24EN50082-1

Weight and Dimensions

Depth	304.8 mm
Width	438.2 mm
Height	88.9 mm
Weight	8200 g
