Cisco 3900 Series, Cisco 2900 Series, and Cisco 1900 Series Integrated Services Routers Generation 2 Software Configuration Guide
Chapter Configuring Ethernet CFM and Y.1731 Performance Monitoring on Layer 3 Interfaces
Support for Y.1731 Performance Monitoring on a Routed Port (L3 Subinterface)
Step 8 end
DETAILED STEPS
Command Purpose
Step 1
enable
Example:
Router> enable
Enables the privileged EXEC mode.
Enter your password when prompted.
Step 2
configure terminal
Example:
Router# configure terminal
Enters the global configuration mode.
Step 3
ip sla operation number
Example:
Router(config)# ip sla 1101
Enables the IP SLA configuration.
operation-number—The IP SLA operation you want to
configure.
Step 4
ethernet y1731 delay DMM domain value
vlan vlan-id mpid value cos value
source mpid value
or
ethernet y1731 delay DMM domain value
vlan vlan-id inner-vlan inner vlan-id
mpid value cos value source mpid
value
Example:
Router(config-ip-sla)# ethernet y1731
delay DMM domain customer vlan 100
mpid 3101 cos 1 source mpid 4101
or
Router(config-ip-sla)# ethernet y1731
delay DMM domain customer vlan 100
inner-vlan 1101 mpid 3101 cos 1
source mpid 4101
Configures a two-way delay measurement.
Note Both single tagging and double tagging are
supported.
The following are the parameters:
• delay—Specifies the delay distribution parameter.
Note DMM is the only supported delay distribution
parameter.
• vlan—Specifies the VLAN.
• inner-vlan—The inner-vlan keyword and the inner
vlan-id argument specify the VLAN tag for
double-tagged packets.
• cos—Specifies the CoS. The value can be any
number between 0 and 7.
Note For double-tagged packets, the cos value
corresponds to the value specified for the
outer tag.
• mpid—Specifies the destination MPID.
• source—Specifies the source MPID.
Step 5
aggregate interval seconds
Example:
Router(config-sla-y1731-delay)#
aggregate interval 30
Configures the Y.1731 aggregation parameter, where
aggregate interval refers to the interval at which the
packets are sent.
seconds—Specifies the length of time, in seconds.

Cisco 2911 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.1Q, IEEE 802.1ag, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3ah, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
DHCP client	-
Routing protocols	BGP, EIGRP, OSPF
Supported protocols	IPv4, IPv6, IS-IS, IGMPv3, PIM SM, SSM, DVMRP, IPSec, GRE, BVD, MPLS, L2TPv3, PPP, MLPPP, MLFR, HDLC, RS-232, RS-449, X.21, V.35, EIA-530, PPPoE, ATM
USB version	2.0
RS-232 ports	1
Expansion slots	4 x EHWIC 2 x DSP 1 x ISM
USB ports quantity	2
Ethernet LAN (RJ-45) ports	3
Firewall security	Cisco IOS
Input current	2.2 A
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	47 - 63 Hz
Power consumption (typical)	50 W
Product color	Black
Rack capacity	2U
Operating altitude	0 - 4000 m
Non-operating altitude	0 - 4570 m
Storage temperature (T-T)	-40 - 80 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 85 %
Safety	UL 60950-1, CAN/CSA C22.2 No. 60950-1, EN 60950-1, AS/NZS 60950-1, IEC 60950-1
Electromagnetic compatibility	47 CFR, ICES-003, EN55022, CISPR22, AS/NZS 3548, VCCI V-3, EN 300-386, EN 61000, EN 55024, CISPR 24EN50082-1

Weight and Dimensions

Depth	304.8 mm
Width	438.2 mm
Height	88.9 mm
Weight	8200 g
