Cisco 3900 Series, Cisco 2900 Series, and Cisco 1900 Series Integrated Services Routers Generation 2 Software Configuration Guide
Chapter Configuring Ethernet Virtual Connection Bridge Domain
Support for Y.1731 Performance Monitoring for EVC BD
Step 4
ethernet y1731 delay dmm domain
domain-name {evc evc-id | vlan
vlan-id} {mpid target-mp-id |
mac-address target-address} cos cos
{source {mpid source-mp-id |
mac-address source-address}}
Example:
Router(config-ip-sla)# ethernet y1731
delay dmm domain xxx evc yyy mpid 101
cos 4 source mpid 100
Begins configuring a single-ended Ethernet delay
operation and enters IP SLA Y.1731 delay configuration
mode.
Step 5
clock sync
Example:
Router(config-sla-y1731-delay)# clock
sync
(Optional) Indicates that the end points are synchronized
and thus allows the operation to calculate one-way delay
measurements.
Step 6
aggregate interval seconds
Example:
Router(config-sla-y1731-delay)#
aggregate interval 900
(Optional) Configures the length of time during which the
performance measurements are conducted and the results
stored.
Step 7
distribution {delay |
delay-variation} one-way
number-of-bins
boundary[,...,boundary]
Example:
Router(config-sla-y1731-delay)#
distribution delay-variation one-way
5 5000,10000,15000,20000,-1
(Optional) Specifies measurement type and configures
bins for statistics distributions kept.
Step 8
frame interval milliseconds
Example:
Router(config-sla-y1731-delay)# frame
interval 100
(Optional) Sets the gap between successive frames.
Step 9
frame offset offset-value
Example:
Router(config-sla-y1731-delay)# frame
offset 1
(Optional) Sets the value for calculating delay variation
values.
Step 10
frame size bytes
Example:
Router(config-sla-y1731-delay)# frame
size 32
(Optional) Configures padding size for frames.
Command Purpose

Cisco 2911 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.1Q, IEEE 802.1ag, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3ah, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
DHCP client	-
Routing protocols	BGP, EIGRP, OSPF
Supported protocols	IPv4, IPv6, IS-IS, IGMPv3, PIM SM, SSM, DVMRP, IPSec, GRE, BVD, MPLS, L2TPv3, PPP, MLPPP, MLFR, HDLC, RS-232, RS-449, X.21, V.35, EIA-530, PPPoE, ATM
USB version	2.0
RS-232 ports	1
Expansion slots	4 x EHWIC 2 x DSP 1 x ISM
USB ports quantity	2
Ethernet LAN (RJ-45) ports	3
Firewall security	Cisco IOS
Input current	2.2 A
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	47 - 63 Hz
Power consumption (typical)	50 W
Product color	Black
Rack capacity	2U
Operating altitude	0 - 4000 m
Non-operating altitude	0 - 4570 m
Storage temperature (T-T)	-40 - 80 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 85 %
Safety	UL 60950-1, CAN/CSA C22.2 No. 60950-1, EN 60950-1, AS/NZS 60950-1, IEC 60950-1
Electromagnetic compatibility	47 CFR, ICES-003, EN55022, CISPR22, AS/NZS 3548, VCCI V-3, EN 300-386, EN 61000, EN 55024, CISPR 24EN50082-1

Weight and Dimensions

Depth	304.8 mm
Width	438.2 mm
Height	88.9 mm
Weight	8200 g
